Characterization of basic physical properties of Sb2Se3 and its relevance for photovoltaics

Chao CHEN, David C. BOBELA, Ye YANG, Shuaicheng LU, Kai ZENG, Cong GE, Bo YANG, Liang GAO, Yang ZHAO, Matthew C. BEARD, Jiang TANG

PDF(480 KB)
PDF(480 KB)
Front. Optoelectron. ›› 2017, Vol. 10 ›› Issue (1) : 18-30. DOI: 10.1007/s12200-017-0702-z
RESEARCH ARTICLE
RESEARCH ARTICLE

Characterization of basic physical properties of Sb2Se3 and its relevance for photovoltaics

Author information +
History +

Abstract

Antimony selenide (Sb2Se3) is a promising absorber material for thin film photovoltaics because of its attractive material, optical and electrical properties. In recent years, the power conversion efficiency (PCE) of Sb2Se3 thin film solar cells has gradually enhanced to 5.6%. In this article, we systematically studied the basic physical properties of Sb2Se3 such as dielectric constant, anisotropic mobility, carrier lifetime, diffusion length, defect depth, defect density and optical band tail states. We believe such a comprehensive characterization of the basic physical properties of Sb2Se3 lays a solid foundation for further optimization of solar device performance.

Graphical abstract

Keywords

antimony selenide (Sb2Se3) / mobility / lifetime / diffusion length / defects
