Preparation of tricalcium silicate and investigation of hydrated cement

Abstract

Tricalcium silicate cement (TSC) has been widely used in dental materials because of its self-setting behavior, good bioactivity, biocompatibility, osteoinductivity, and antibacterial effect. Tricalcium silicate (C₃S) powder was prepared by Pechini technique with a calcining temperature of 1300 °C for 3 h. The influence of liquid/powder (L/P) rate on the setting time and the mechanical property of TSC was studied. Characterization methods including XRD, FTIR, SEM-EDS, TEM, and ICP-AES were utilized to study the properties of C₃S powder and its hydrated cement. The bioactivity and biocompatibility of the cement were investigated by soaking test and cell culture, respectively. The results show that the L/P rate plays an important role in the setting time and the compressive strength of TSC. The surface of TSC was covered by hydroxyapatite deposition during the immersion experiment and the cells attachment on the surface of TSC was well, which indicated that TSC has good bioactivity and biocompatibility. In addition, TSC has excellent antibacterial properties against Staphylococcus aureus. In conclusion, TSC is a promising candidate for root canal filling materials.

Keywords

tricalcium silicate powder / chemical synthesis / inorganic compounds / microstructure

References

[1] LimJ, GukJ G, SinghB, HwangY C, SongS J, KimH S. Investigation on hydration process and biocompatibility of calcium silicate-based experimental portland cements [J]. Journal of the Korean Ceramic Society, 2019, 56(4): 403-411

[2] TorabinejadM, ParirokhM, DummerP M H. Mineral trioxide aggregate and other bioactive endodontic cements: An updated overview-part II: Other clinical applications and complications [J]. International Endodontic Journal, 2018, 51(3): 284-317

[3] ParirokhM, TorabinejadM, DummerP M H. Mineral trioxide aggregate and other bioactive endodontic cements: An updated overview-part I: Vital pulp therapy [J]. International Endodontic Journal, 2018, 51(2): 177-205

[4] HosoyaN, TakigawaT, HorieT, MaedaH, YamamotoY, MomoiY, YamamotoK, OkijiT. A review of the literature on the efficacy of mineral trioxide aggregate in conservative dentistry [J]. Dental Materials Journal, 2019, 38(5): 693-700

[5] MeschiN, LiX, vanG G, CamilleriJ, vanM B, LambrechtsP. Bioactivity potential of Portland cement in regenerative endodontic procedures: From clinic to lab [J]. Dental Materials, 2019, 35(9): 1342-1350

[6] TaddeiP, TintiA, GandolfiM G, RossiP L, PratiC. Ageing of calcium silicate cements for endodontic use in simulated body fluids: A micro-Raman study [J]. Journal of Raman Spectroscopy, 2009, 40(12): 1858-1866

[7] CamilleriJ. Characterization and hydration kinetics of tricalcium silicate cement for use as a dental biomaterial [J]. Dental Materials, 2011, 27(8): 836-844

[8] DawoodA E, ParashosP, WongR H K, ReynoldsE C, MantonD J. Calcium silicate-based cements: Composition, properties, and clinical applications [J]. Journal of Investigative and Clinical Dentistry, 2017, 8(2): 1-15

[9] DuarteM A H, MarcianoM A, VivanR R, TanomaruF M, TanomaruJ M G, CamilleriJ. Tricalcium silicate-based cements: Properties and modifications [J]. Brazilian Oral Research, 2018, 32(S1): 111-118

[10] AbusrewilS M, McleanW, ScottJ A. The use of bioceramics as root-end filling materials in periradicular surgery: A literature review [J]. Saudi Dental Journal, 2018, 30(4): 273-282

[11] JafariF, JafariS. Composition and physicochemical properties of calcium silicate based sealers: A review article [J]. Journal of Clinical and Experimental Dentistry, 2017, 9: 1249-1255

[12] LiuW-j, ZhaiD, HuanZ-g, WuC, ChangJiang. Novel tricalcium silicate/magnesium phosphate composite bone cement having high compressive strength, in vitro bioactivity and cytocompatibility [J]. Acta Biomaterialia, 2015, 21: 217-227

[13] LeeS J, MonsefM, TorabinejadM. Sealing ability of a mineral trioxide aggregate for repair of lateral root perforations [J]. Journal of Endodontics, 1993, 19(11): 541-544

[14] SiboniF A O, TaddeiP, ZampariniF, PratiC, GandolfiM G. Properties of BioRoot RCS, a tricalcium silicate endodontic sealer modified with povidone and polycarboxylate [J]. International Endodontic Journal, 2017, 50: 120-136

[15] YamamotoS, HanL, NoiriY, OkijiT. Evaluation of the Ca ion release, pH and surface apatite formation of a prototype tricalcium silicate cement [J]. International Endodontic Journal, 2017, 50: 73-82

[16] ZhaoW-y, ChangJiang. Two-step precipitation preparation and self-setting properties of tricalcium silicate [J]. Materials Science and Engineering C, 2008, 28(2): 289-293

[17] ZhouY-l, XuC, WangX-y, DouY-d, HuanZ-g, ChangJiang. Fast setting tricalcium silicate/magnesium phosphate premixed cement for root canal filling [J]. Ceramics International, 2018, 44(3): 3015-3023

[18] BellmannF, DamidotD, MöserB, SkibstedJ. Improved evidence for the existence of an intermediate phase during hydration of tricalcium silicate [J]. Cement and Concrete Research, 2010, 40(6): 875-884

[19] El-HamidH K, Abo-AlmagedH H, RadwanM M. Synthesis, characterization and antimicrobial activity of nano-crystalline tricalcium silicate bio-cement [J]. Journal of Applied Pharmaceutical Science, 2017, 7: 1-8

[20] SorrentinoF. Upscaling the synthesis of tricalcium silicate and alite [J]. Cement Wapno Beton, 2008, 8: 177-183

[21] FloresgarayK A, MartínezluévanosA, CruzortizB R, GarcíacerdaL A, LópezbadilloC M. Synthesis of calcium silicates by Pechini method and exchanging ions of sodium alginate-calcium chloride [J]. Journal of the Spanish Ceramic and Glass Society, 2016, 55(6): 239-245(in Spanish)

[22] GakiA, PerrakiT, KakaliG. Wet chemical synthesis of monocalcium aluminate [J]. Journal of the European Ceramic Society, 2007, 27(2): 1785-1789

[23] TanY-n, LiuY, ZhangQ, GurpreetB L. Synthesis of pure dicalcium silicate powder by the pechini method and characterization of hydrated cement [J]. Materials Science Forum, 2014, 787: 387-394

[24] KokuboT, TakadamaH. How useful is SBF in predicting in vivo bone bioactivity? [J]. Biomaterials, 2006, 27(15): 2907-2915

[25] ISO/EN 10993-5. Biological evaluation of medical devices-Part 5. Tests for cytotoxicity, in vitro methods: 8.2 tests on extract [S].

[26] LiuW C, WangH Y, ChenL C, HuangS W, WuC T, ChungR J. Hydroxyapatite/tricalcium silicate composites cement derived from novel two-step sol-gel process with good biocompatibility and applications as bone cement and potential coating materials [J]. Ceramics International, 2019, 45(5): 5668-5679

[27] PratiC, GandolfiM G. Calcium silicate bioactive cements: Biological perspectives and clinical applications [J]. Dental Materials, 2015, 31(4): 351-370

[28] GrechL, MalliaB, CamilleriJ. Investigation of the physical properties of tricalcium silicate cement-based root-end filling materials [J]. Dent Mater, 2013, 29(2): e20-e28

[29] LiuW C, HuC C, TsengY Y, SakthivelR, FanK S, WangA N, WangY M, ChungR J. Study on strontium doped tricalcium silicate synthesized through sol-gel process [J]. Materials Science and Engineering C, 2020, 108: 110431

[30] CamilleriJ, SorrentinoF, DamidotD. Investigation of the hydration and bioactivity of radiopacified tricalcium silicate cement, biodentine and MTA Angelus [J]. Dental Materials, 2013, 29(5): 580-593

[31] ThomasJ J. A new approach to modeling the nucleation and growth kinetics of tricalcium silicate hydration [J]. Journal of the American Ceramic Society, 2007, 90(10): 3282-3288

[32] CuestaA, Zea-GarciaJ D, Londono-ZuluagaD, de la TorreA G, SantacruzI, VallcorbaO, DapiaggiM, SanfélixS G, ArandaM A G. Multiscale understanding of tricalcium silicate hydration reactions [J]. Scientific Reports, 2018, 8(1): 8544-8565

[33] JuengerM C G, MonteiroP J M, GartnerE M, DenbeauxG P. A soft X-ray microscope investigation into the effects of calcium chloride on tricalcium silicate hydration [J]. Cement and Concrete Research, 2005, 35(1): 19-25

[34] FRANUS W, PANEK R, WDOWIN M. SEM Investigation of microstructures in hydration products of portland cement [C]//POLYCHRONIADIS E K, ORAL A Y, OZER M. 2nd International Multidisciplinary Microscopy and Microanalysis Congress. Springer International Publishing, 2015: 105–112.

[35] CALLEBAUT K, ELSEN J, van BALEN K, VIAENE W. Historical and scientific study of hydraulic mortars from the 19th century [C]//BARTOS P, GROOT C, HUGHES J. International RILEM Workshop on Historic Mortars: Characteristics and Tests. 2000: 125–133.

[36] HaoF-y, QinL-m, LiuJ-d, ChangJ, HuanZ-g, WuLin. Assessment of calcium sulfate hemihydrate-tricalcium silicate composite for bone healing in a rabbit femoral condyle model [J]. Materials Science and Engineering C, 2018, 8853-60

[37] SousaA, SouzaK C, SousaE M B. Mesoporous silica/apatite nanocomposite: Special synthesis route to control local drug delivery [J]. Acta Biomaterialia, 2008, 4(3): 671-679

[38] ZhouX-f, ZhangN-l, MankociS, SahaiN. Silicates in orthopedics and bone tissue engineering materials [J]. Journal Biomedical Materials Research A, 2017, 105(7): 2090-2102

[39] NingC-q, MehtaJ, El-GhannamA. Effects of silica on the bioactivity of calcium phosphate composites in vitro [J]. Journal of Materials Science: Materials in Medicine, 2005, 16(4): 355-360

[40] WuM, TaoB-l, WangT, ZhangY, WeiW-c, WangC-yu. Fast-setting and anti-washout tricalcium silicate/disodium hydrogen phosphate composite cement for dental application [J]. Ceramics International, 2019, 45(18): 24182-24192

[41] NataleL C, RodriguesM C, XavierT A, SimõesA, DeS D N, BragaR R. Ion release and mechanical properties of calcium silicate and calcium hydroxide materials used for pulp capping [J]. International Endodontic Journal, 2015, 48(1): 89-94

[42] XuC, WenY, ZhouY-l, ZhuY-q, DouY-d, HuanZ-g, ChangJiang. In vitro self-setting properties, bioactivity, and antibacterial ability of a silicate-based premixed bone cement [J]. International Journal of Applied Ceramic Technology, 2018, 15(2): 460-471

[43] RanS-j, LiuB, JiangW, SunZ, LiangJ-ping. Transcriptome analysis of enterococcus faecalis in response to alkaline stress [J]. Frontiers in Microbiology, 2015, 6: 1-11
