Numerical study of a parabolic-trough CPV-T collector with spectral-splitting liquid filters

Abstract

Conventional flat-plate photovoltaic-thermal (PV-T) collectors generate electricity and heat simultaneously; however, the outlet temperature of the latter is typically below 60 °C, limiting their widespread application. The use of optical concentration can enable higher-temperature heat to be generated, but this can also lead to a rise in the operating temperature of the PV cells in the collector and, in turn, to a deterioration in their electrical performance. To overcome this challenge, an optical spectral-splitting filter that absorbs the infrared and transmits the visible portion of the solar spectrum can be used, such that wavelengths below the bandgap are sent to the cells for electricity generation, while those above it are sent to a thermally decoupled absorber for the generation of heat at a temperature that is considerably higher than that of the cells. In this study, a triangular primary PV-T channel, wherein the primary heat transfer fluid (water) flows, is integrated into a parabolic trough concentrator of geometrical concentration ratio ~10, while a secondary liquid filter (water, AgSiO₂-eg or Therminol-66) is introduced for spectral splitting. Optical, electrical and thermal-fluid (sub-)models are developed and coupled to study the performance of this collector. Each sub-model is individually checked against results taken from the literature with maximum deviations under 10%. Subsequently, the optical and electrical models are coupled with a 3-D thermal-fluid CFD model (using COMSOL Multiphysics 6.1) to predict the electrical and thermal performance of the collector. Results show that when water is used as the optical filter, the maximum overall thermal (filter channel plus primary channel) and electrical efficiencies of the collector reach ~45% and 15%, respectively. A comparison between water, AgSiO₂-eg and Therminol-66 reveals that AgSiO₂-eg improves the thermal efficiency of the filter channel by ~25% (absolute) compared to Therminol-66 and water, however, this improvement – which arises from the thermal performance of the filter – comes at an expense of a ~5% electrical efficiency loss.

Graphical abstract

Keywords

concentrator / filter / photovoltaic-thermal / solar energy / spectral splitting
