Production of (R)-mandelic acid from styrene, L-phenylalanine, glycerol, or glucose via cascade biotransformations

Abstract

(R)-mandelic acid is an industrially important chemical, especially used for producing antibiotics. Its chemical synthesis often uses highly toxic cyanide to produce its racemic form, followed by kinetic resolution with 50% maximum yield. Here we report a green and sustainable biocatalytic method for producing (R)-mandelic acid from easily available styrene, biobased L-phenylalanine, and renewable feedstocks such as glycerol and glucose, respectively. An epoxidation-hydrolysis-double oxidation artificial enzyme cascade was developed to produce (R)-mandelic acid at 1.52 g/L from styrene with > 99% ee. Incorporation of deamination and decarboxylation into the above cascade enables direct conversion of L-phenylalanine to (R)-mandelic acid at 913 mg/L and > 99% ee. Expressing the five-enzyme cascade in an L-phenylalanine-overproducing E. coli NST74 strain led to the direct synthesis of (R)-mandelic acid from glycerol or glucose, affording 228 or 152 mg/L product via fermentation. Moreover, coupling of E. coli cells expressing L-phenylalanine biosynthesis pathway with E. coli cells expressing the artificial enzyme cascade enabled the production of 760 or 455 mg/L (R)-mandelic acid from glycerol or glucose. These simple, safe, and green methods show great potential in producing (R)-mandelic acid from renewable feedstocks.

Keywords

Sustainable synthesis / Cascade reaction / Biotransformation / Mandelic acid / Renewable feedstocks / Coupled-cells biotransformation / L-phenylalanine / Styrene

References

[1] Aston JG, Newkirk JD, Jenkins DM, Dorsky J. Mandelic acid. Org Synth, 2003, 538: 48-48.

[2] Becker J, Wittmann C. Advanced biotechnology: metabolically engineered cells for the bio-based production of chemicals and fuels, materials, and health-care products. Angew Chem Int Ed, 2015, 54(11): 3328-3350.

[3] Bhatia SK, Mehta PK, Bhatia RK, Bhalla TC. Optimization of arylacetonitrilase production from Alcaligenes sp. MTCC 10675 and its application in mandelic acid synthesis. Appl Microbiol Biotechnol, 2014, 98: 83-94.

[4] Biermann U, Bornscheuer U, Meier MAR, Metzger JO, Schäfer HJ. Oils and fats as renewable raw materials in chemistry. Angew Chem Int Ed, 2011, 50(17): 3854-3871.

[5] Blacker AJ, Houson IN (2002) Preparation of mandelic acid derivatives. WO Patent 2002066410A1. 29 Aug 2002

[6] Bornscheuer UT, Huisman GW, Kazlauskas RJ, Lutz S, Moore JC, Robins K. Engineering the third wave of biocatalysis. Nature, 2012, 485: 185-194.

[7] Chen X, Yang C, Wang P, . Stereoselective biotransformation of racemic mandelic acid using immobilized laccase and (S)-mandelate dehydrogenase. Bioresour Bioprocess, 2017, 4(1): 2.

[8] Choi YJ, Tribe DE. Continuous production of phenylalanine using an Escherichia coli regulatory mutant. Biotechnol Lett, 1982, 4(4): 223-228.

[9] Christensen CH, Rass-Hansen J, Marsden CC, Taarning E, Egeblad K. The renewable chemicals industry. Chemsuschem, 2008, 1(4): 283-289.

[10] Corson B, Dodge RA, Harris S, Yeaw J. Mandelic acid. Org Synth, 2003, 6: 58-58.

[11] Detzel C, Maas R, Jose J. Autodisplay of nitrilase from Alcaligenes faecalis in E. coli yields a whole cell biocatalyst for the synthesis of enantiomerically pure (R)-mandelic acid. ChemCatChem, 2011, 3: 719-725.

[12] Heuts DPHM, Van Hellemond EW, Janssen DB, Fraaije M. Discovery, characterization, and kinetic analysis of an alditol oxidase from Streptomyces coelicolor. J Biol Chem, 2007, 282(28): 20283-20291.

[13] Dong J, Fernández-Fueyo E, Hollmann F, . Biocatalytic oxidation reactions: a chemist's perspective. Angew Chem, Int Ed, 2018, 57(30): 9238-9261.

[14] Gandomkar S, Żądło-Dobrowolska A, Kroutil W. Extending designed linear biocatalytic cascades for organic synthesis. ChemCatChem, 2019, 11(1): 225-243.

[15] He YC, Xu JH, Xu Y, Ouyang LM, Pan J. Biocatalytic synthesis of (R)-(-)-mandelic acid from racemic mandelonitrile by a newly isolated nitrilase-producer Alcaligenes sp. ECU0401. Chin Chem Lett, 2007, 18: 677-680.

[16] Jiang W, Tao R, Yang Y, . Production of (R)-(-)-mandelic acid with nitrilase immobilized on D155 resin modified by L-lysine. Biochem Eng J, 2017, 127: 32-42.

[17] Jiang X-P, Lu T-T, Liu C-H, . Immobilization of dehydrogenase onto epoxy-functionalized nanoparticles for synthesis of (R)-mandelic acid. Int J Biol Macromol, 2016, 88: 9-17.

[18] Keasling JD. Manufacturing molecules through metabolic engineering. Science, 2010, 330: 1355-1358.

[19] Kinbara K, Sakai K, Hashimoto Y, Nohira H, Saigo K. Design of resolving reagents: p-substituted mandelic acids as resolving reagents for 1-arylalkylamines. Tetrahedron Asymmtry, 1996, 7: 1539-1542.

[20] Lee JW, Na D, Park JM, Lee J, Choi S, Lee SY. Systems metabolic engineering of microorganisms for natural and non-natural chemicals. Nat Chem Biol, 2012, 8: 536-546.

[21] Li G-Y, Huang K-L, Jiang Y-R, Ding P. Production of (R)-mandelic acid by immobilized cells of Saccharomyces cerevisiae on chitosan carrier. Process Biochem, 2007, 42: 1465-1469.

[22] Lukito BR, Sekar BS, Wu S, Li Z. Whole cell-based cascade biotransformation for the production of (S)-mandelic acid from styrene, L-phenylalanine, glucose, or glycerol. Adv Synth Catal, 2019

[23] Lukito BR, Wu S, Saw HJJ, Li Z. One-pot production of natural 2-phenylethanol from L-phenylalanine via cascade biotransformations. ChemCatChem, 2019, 11(2): 831-840.

[24] Mills J, Schmiegel KK, Shaw WN (1983) Phenethanolamines, compositions containing the same, and method for effecting weight control. US Patent US4391826A. 5 Jul 1983

[25] Nielsen J, Keasling Jay D. Engineering cellular metabolism. Cell, 2016, 164: 1185-1197.

[26] Reetz MT. Biocatalysis in organic chemistry and biotechnology: past, present, and future. J Am Chem Soc, 2013, 135(34): 12480-12496.

[27] Reifenrath M, Boles E. Engineering of hydroxymandelate synthases and the aromatic amino acid pathway enables de novo biosynthesis of mandelic and 4-hydroxymandelic acid with Saccharomyces cerevisiae. Metab Eng, 2018, 45: 246-254.

[28] Schrittwieser JH, Velikogne S, Hall M, Kroutil W. Artificial biocatalytic linear cascades for preparation of organic molecules. Chem Rev, 2018, 118(1): 270-348.

[29] Sekar BS, Lukito BR, Li Z. Production of natural 2-phenylethanol from glucose or glycerol with coupled Escherichia coli strains expressing L-phenylalanine biosynthesis pathway and artificial biocascades. ACS Sustain Chem Eng, 2019, 7: 12231-12239.

[30] Sun Z, Ning Y, Liu L, . Metabolic engineering of the L-phenylalanine pathway in Escherichia coli for the production of S- or R-mandelic acid. Microb Cell Fact, 2011, 10: 71.

[31] Surivet J-P, Vatèle J-M. Total synthesis of antitumor Goniothalamus styryllactones. Tetrahedron, 1999, 55: 13011-13028.

[32] Tuck CO, Pérez E, Horváth IT, Sheldon RA, Poliakoff M. Valorization of biomass: deriving more value from waste. Science, 2012, 337: 695-699.

[33] van Hellemond EW, Vermote L, Koolen W, . Exploring the biocatalytic scope of alditol oxidase from Streptomyces coelicolor. Adv Synth Catal, 2009, 351(10): 1523-1530.

[34] Vennestrøm PNR, Osmundsen CM, Christensen CH, Taarning E. Beyond petrochemicals: the renewable chemicals industry. Angew Chem, Int Ed, 2011, 50: 10502-10509.

[35] Wang H, Fan H, Sun H, Zhao L, Wei D. Process development for the production of (R)-(-)-mandelic acid by recombinant Escherichia coli cells harboring nitrilase from Burkholderia cenocepacia J2315. Org Process Res Dev, 2015, 19: 2012-2016.

[36] Whitesell JK, Reynolds D. Resolution of chiral alcohols with mandelic acid. J Org Chem, 1983, 48: 3548-3551.

[37] Winkler M, Geier M, Hanlon Steven P, Nidetzky B, Glieder A. Human enzymes for organic synthesis. Angew Chem Int Ed, 2018

[38] Woolston BM, Edgar S, Stephanopoulos G. Metabolic engineering: past and future. Annu Rev Chem Biomol Eng, 2013, 4: 259-288.

[39] Wu S, Li A, Chin YS, Li Z. Enantioselective hydrolysis of racemic and meso-epoxides with recombinant Escherichia coli expressing epoxide hydrolase from Sphingomonas sp. HXN-200: preparation of epoxides and vicinal diols in high ee and high concentration. ACS Catalysis, 2013, 3(4): 752-759.

[40] Wu S, Li Z. Whole-cell cascade biotransformations for one-pot multistep organic synthesis. ChemCatChem, 2018, 10(10): 2164-2178.

[41] Wu S, Snajdrova R, Moore JC, Baldenius K, Bornscheuer UT. Biocatalysis: enzymatic synthesis for industrial applications. Angew Chem Int Ed, 2020, 59: 2-34.

[42] Wu S, Zhou Y, Seet D, Li Z. Regio- and stereoselective oxidation of styrene derivatives to arylalkanoic acids via one-pot cascade biotransformations. Adv Synth Catal, 2017, 359(12): 2132-2141.

[43] Xiao M-T, Huang Y-Y, Shi X-A, Guo Y-H. Bioreduction of phenylglyoxylic acid to R-(-)-mandelic acid by Saccharomyces cerevisiae FD11b. Enzyme Microb Technol, 2005, 37: 589-596.

[44] Yutthalekha T, Warakulwit C, Limtrakul J, Kuhn A. Enantioselective recognition of DOPA by mesoporous platinum imprinted with mandelic acid. Electroanalysis, 2015, 27: 2209-2213.

[45] Zhang Z-J, Xu J-H, He Y-C, Ouyang L-M, Liu Y-Y, Imanaka T. Efficient production of (R)-(-)-mandelic acid with highly substrate/product tolerant and enantioselective nitrilase of recombinant Alcaligenes sp. Process Biochem, 2010, 45: 887-891.

[46] Zhimin O, Ma L, Niu Y, Cui J. Preparation of (R)-(-)-mandelic acid by two-step biotransformation of ethyl benzoylformate. Biocatal Biotransfor, 2017

[47] Zhou Y, Wu S, Li Z. Cascade biocatalysis for sustainable asymmetric synthesis: from biobased L-Phenylalanine to high-value chiral chemicals. Angew Chem, Int Ed, 2016, 55(38): 11647-11650.

[48] Zhou Y, Wu S, Mao J, Li Z. Bioproduction of benzylamine from renewable feedstocks via a nine-step artificial enzyme cascade and engineered metabolic pathways. Chemsuschem, 2018, 11(13): 2221-2228.

Funding

National Research Foundation (NRF) Singapore(A1783c0014)
